Product Data
A 45
Type : Floor standing speaker
Engineering Principle : 3-way Downfire bass reflex system
Nom. /Music power handling : 170 / 340 watts
SPL (1 watt/1m) : 88.5 db
Frequency response : 22…40.000 Hz
Crossover frequency : 220 / 3.000 Hz
Woofer : 3 x 174 mm, Aluminum ceramic tungsten (wave-sicke)
Midrange : 1 x 174 mm, aluminum ceramic tungsten (wave-sicke, TCC)
Tweeter : 1 x 25 mm, aluminum oxyd ceramic
Nominal Impedance : 4...8 Ohm
Special Features
DC technology
Fabric cover with magnetic holding
Gold Bi-Wiring/Bi-Amping Connector Field
Dimensions (WxHxD)
W: 22.5 cm | 33 cm with socket
H: 107 cm with sockets and device feet
D: 40 cm | 43 cm with socket
Weight : 38 Kg
AV receiver and stereo receiver
Carton Content
A 45
Equipment feet
Fabric cover with magnetic holding
Operating instructions
A 45 CS
Type : high-end center speaker
Engineering Principle : 3-way, bass reflex system
Nom. /Music power handling : 120 / 220 watts
SPL (1 watt/1m) : 87 db
Frequency response : 26…40.000 Hz
Crossover frequency : 300 / 3.000 Hz
Woofer : 1 x 180 mm (7''), Aluminum (wave surround)
Midrange : 1 x 180 mm, aluminum ceramic tungsten (wave-sicke, TCC)
Tweeter : 1 x 25 mm (1''), aluminum oxyd ceramic
Nominal Impedance : 4...8 Ohm
Special Features
High-End Cable System
gold plated bi-wiring/bi-amping screwclamp terminals
fabric grill with magnetic mount
Dimensions (WxHxD) : 70 x 20 x 35 cm (27.6 x 7.9 x 13.8)
Weight : 16.5 Kg
Available accessories : LS 850.3
Carton Content
A 45 CS
Fabric cover with magnetic holding (black)
Equipment feet (rubber)
Operating instructions
A 45 BS
Type : Compact Speaker
Engineering Principle : 2-way, bass reflex system
Nom. /Music power handling : 120 / 200 watts
SPL (1 watt/1m) : 87 db
Frequency response : 25…40.000 Hz
Crossover frequency : 3.000 Hz
Woofer : 1 x 174 mm, aluminum ceramic tungsten (Wavesurround)
Tweeter : 1 x 25 mm, aluminum oxyd ceramic
Nominal Impedance : 4...8 Ohm
Special Features
Gold Bi-Wiring/Bi-Amping Connector Field
High-End Inside Cabling CantoLink 400
DC technology
Fabric tension with magnetic holding
Thread pins in the housing for A 45 LS
Dimensions (WxHxD)
W: 22.5 cm
H: 40 cm
D: 36.5 cm | 37.2 cm with fabric tension
Weight : 14 Kg
Available accessories
A 45 LS (Loudspeaker stand)
CantoLink 400 (speaker cable)
Carton Content
A 45 BS
Fabric tension (black)
Operating instructions
Rubber feet
A 45 SUB
Type : High-End active subwoofer
Engineering Principle : bass reflex system with passive membrane
Nom. /Music power handling : 500 / 750 watts
Frequency response : 18…200 Hz
Crossover frequency : 55…200 Hz (adjustable)
Woofer
1 x 310 mm (12'') aluminium-ceramic-tungsten
1 x 310 mm (12'') cellulose-graphit (passive)
Connection
2 high level inputs (loudspeaker cable)
2 low level inputs (chinch)
Features
Automatic on/off switch
IR remote
adjustable volume
Adjustable phase limiter
Adjustable crossover frequency
Special Features : Bass-Guide
Dimensions (WxHxD)
42 x 54 x 50 cm
16.5'' x 21'' x 19.7
Weight : 33 Kg
Carton Content
A 45 SUB
remote control
magnetic holding device control
manual
