Product Data
C 309
Type : Floorstanding speaker
Engineering Principle : 3-way bass reflex
Nom. /Music power handling : 160 / 320 watts
SPL (1 watt/1m) : 88.3 dB
Frequency response : 20…40.000 Hz
Crossover frequency : 300 / 3.000 Hz
Woofer : 2 x 180 mm (7''), Aluminum (Wave surround)
Midrange : 1 x 180 mm (7''), Aluminum (Wave surround)
Tweeter : 1 x 25 mm (1"), aluminum-manganese
Special Features
DC-technology
Aluminum Frontgrill
Nominal Impedance : 4…8 ohms
Dimensions (WxHxD) : 24 x 105 x 30 cm (9.5'' x 41.3'' x 11.8'')
Weight : 23 kg
Carton Content
GLE 9
Manual
C 305
Type : Centerspeaker
Engineering Principle : 3-way bass reflex
Nom. /Music power handling : 85 / 140 watts
SPL (1 watt/1m) : 87.5 dB
Frequency response : 32…40.000 Hz
Crossover frequency : 350 / 3.000 Hz
Woofer : 1 x 160 mm (6"), aluminium (Wave surround)
Midrange : 1 x 160 mm (6''), Aluminum (Wave surround)
Tweeter : 1 x 25 mm (1"), aluminum-manganese
Special Features : Aluminum Frontgrill
Nominal Impedance : 4…8 ohms
Dimensions (WxHxD) : 45,5 x 17 x 30 cm (17.9'' x 6.7'' x 11.8'')
Weight : 9 kg
Available accessories
Loudspeaker stand LS 600.2
Loudspeaker stand LS 750
Carton Content
GLS 5
Euqipment feet
Manual
C 302
Type : Compact speaker
Engineering Principle : 2-way bass reflex
Nom. /Music power handling : 60 / 100 watts
Woofer : 1 x 160 mm (6''), Aluminum (Wave surround)
Tweeter : 1 x 25 mm (1''), aluminum-manganese
Nominal Impedance : 4...8 ohmss
Special Features : Powdered steel grid
Available accessories
Loudspeaker stand LS 600.2
Loudspeaker stand LS 650
Carton Content
GLS 2
Equipment feet
Manual
SUB 300
Type : Active Subwoofer system
Engineering Principle : Bassreflex with passive membrane
Nom. /Music power handling : 200 / 350 watts
Crossover frequency : 50...200 Hz (adjustable)
Woofer
1 x 310 mm (12.2“), Aluminium (Wave-Surround)
1 x 310 mm (12.2“), Aluminium (passive)
Connection
2 x high level inputs (loudspeakercable)
2 x low level inputs (Cinch)
Special Features
Automatic on/off switch
adjustable volume
adjustable phase limiter
adjustable crossover frequency
Dimensions (WxHxD) : 36 x 48 x 50 cm (14.2‘‘ x 18.1‘‘ x 19.7‘‘)
