Integrated Amplifier
Input Option : RCA Line Input X 2, 3.5 φ Line Input X 1
Power Output : > 20 W (1KHz THD 10% Max Output)
Load Impedance 4 OHM : > 35 W (THD 10% Max Output)
Input Sensitivity : 210 mV
Input Impedance : 20K OHM
Distortion : < 0.5% (1KHz 1W / 4 OHM 20Hz ~ 20K Hz)
Frequency Response : 20 ~ 20K Hz (Volume at Max 1W Output -3dB)
Separation : > 60 dB
Min. Hum Volume at Min. : < 10 mV (20K LPF)
D/A Converter
Input Option : USB x 1, OPTICAL x 1, COAXIAL x 1
Output Option : ANALOG RCA OUTPUT x 1, 1V AND 2V SELECT SWITCH x 1
Output Level : ± 0.2 V
Distortion : < 0.05%
S/N : 100 dB
Output Impedance : < 600 OHM
Separation : 100 dB
Frequency Response : ± 3 dB (20~20KHz)
Dimension : W 140 x H 48 x D160 mm
Integrated Amplifier
Input Option : RCA Line Input X 2, 3.5 φ Line Input X 1
Power Output : > 20 W (1KHz THD 10% Max Output)
Load Impedance 4 OHM : > 35 W (THD 10% Max Output)
Input Sensitivity : 210 mV
Input Impedance : 20K OHM
Distortion : < 0.5% (1KHz 1W / 4 OHM 20Hz ~ 20K Hz)
Frequency Response : 20 ~ 20K Hz (Volume at Max 1W Output -3dB)
Separation : > 60 dB
Min. Hum Volume at Min. : < 10 mV (20K LPF)
D/A Converter
Input Option : USB x 1, OPTICAL x 1, COAXIAL x 1
Output Option : ANALOG RCA OUTPUT x 1, 1V AND 2V SELECT SWITCH x 1
Output Level : ± 0.2 V
Distortion : < 0.05%
S/N : 100 dB
Output Impedance : < 600 OHM
Separation : 100 dB
Frequency Response : ± 3 dB (20~20KHz)
Dimension : W 140 x H 48 x D160 mm
